ITECH IT2806 Graphical Source Measure Unit (200 V, 3 A DC/ 10 A Pulse, 20 W)

Output Ratings:

  • Voltage/Current: 200 V, 3 A DC/ 10 A Pulse
  • Power: 20 W
  • Current resolution: Minimum 10 fA

Feature set:

  • Combing the capabilities of six devices in one: Voltage Source, Current
  • Source, 6 ½ Digital Multimeter (DCV,DCI, ohms), Battery Simulator, electronic load and Pulse Generator
  • Integrating 4-quadrant sourcing & measuring capabilities, and supporting Two-wire & Four-wire measurement
  • 5 inch touch display supports both graphical and numerical view modes.
  • Resolution up to 10 fA/100 nV, sampling rate up to 10 us.
  • Three graphic display modes: Graph View, Scope View and Record View.
  • Built-in battery simulator function, suitable for IOT low power precision measurement
  • Sweep Capability: Linear/Log/ Pulsed-line AR/Pulsed-Log and LIST
  • Multi-channel and simultaneous operation design, with parallel testing capability
  • Built-in resistance, power, and Math measurement features
  • GUARD output function, suitable for low current measurement
  • Front USB port used for data storage, screen capture, or test configuration import

Connectivity:

  • Built-in Digital IO/USB/LAN communication interface
  • Optional GPIB
  • Support SCPI, LabVIEW programming

Documents and Software Solutions:

Product Number:

IT2806

Manufacturer:

ITECH

Quantity:

Total
Unit price
base price
Stock
Call or email for delivery time

The IT2800 Series are compact and cost-effective bench-top Source Measure Units (SMUs) with the capability to source and measure both voltage and current. These capabilities make the IT2800 Series ideal for a wide variety of IV (current versus voltage) measurement tasks that require both high resolution and accuracy.

The IT2800 Series combine the capabilities of a voltage source, a current source, a voltage meter, a current meter and an ohmmeter (along with the capability to switch easily between these various functions). This ensures the independent measurement of IV characteristic in 4-quadrant. Easily and accurately measure current and voltage using a single instrument without the need to manually change any connections.

Besides, the IT2800 Series(SMU) also possess a voltage and current limit feature that allows the user to set limits and to protect devices from damage. Besides, it also provides a broad range of IV measurements for various double or triple terminal devices.

With a current range of 10 fA to 10 A and a voltage range of 100nV to 1000V, the IT2800 series SMU has capabilities that allow it to perform more than just simple DC and pulsed measurements to prevent errors in measurement results due to the device's own heating. In addition, the IT2800 series SMUs are equipped with high-speed, reliable fiber optic parallel mode, which enables them to work stably and reliably among multiple SMUs and exchange large amounts of data to fulfill a wide variety of test requirements. Excellent Front Panel GUI with 5 inch touch display supports various view modes, to help engineers significantly improve the efficiency of testing.

Description
Additional Informations
Reviews
Query on the Item
Do you have any questions on this item?
Your E-mail Address
My Question:
Please retype the letters shown here
captcha
Description
Reviews
Query on the Item

The IT2800 Series are compact and cost-effective bench-top Source Measure Units (SMUs) with the capability to source and measure both voltage and current. These capabilities make the IT2800 Series ideal for a wide variety of IV (current versus voltage) measurement tasks that require both high resolution and accuracy.

The IT2800 Series combine the capabilities of a voltage source, a current source, a voltage meter, a current meter and an ohmmeter (along with the capability to switch easily between these various functions). This ensures the independent measurement of IV characteristic in 4-quadrant. Easily and accurately measure current and voltage using a single instrument without the need to manually change any connections.

Besides, the IT2800 Series(SMU) also possess a voltage and current limit feature that allows the user to set limits and to protect devices from damage. Besides, it also provides a broad range of IV measurements for various double or triple terminal devices.

With a current range of 10 fA to 10 A and a voltage range of 100nV to 1000V, the IT2800 series SMU has capabilities that allow it to perform more than just simple DC and pulsed measurements to prevent errors in measurement results due to the device's own heating. In addition, the IT2800 series SMUs are equipped with high-speed, reliable fiber optic parallel mode, which enables them to work stably and reliably among multiple SMUs and exchange large amounts of data to fulfill a wide variety of test requirements. Excellent Front Panel GUI with 5 inch touch display supports various view modes, to help engineers significantly improve the efficiency of testing.
