Keysight PNTX100A PNT Xe Simulation System
CRPA and signal capabilities
- Support 16+ element CRPAs with continuous high dynamic range for interference signals
- Generate carrier phase-aligned wavefronts using purpose-designed, optimized software-defined radio (SDR) technology
Classified testing
- Test using GPS Directorate-approved MNSA M-Code, AES M-Code, server-based SDS M-Code, SA/A-S, and RMP
- Support Galileo PRS signals through an established partnership with Fraunhofer IIS
Navigation warfare (NAVWAR) emulation
- Emulate a full range of spoofing and jamming threats with high dynamic range across all signal outputs
- Simulate contested environments at scale to validate system resilience under realistic NAVWAR conditions
Control and automation
- Automate testing via SimREMOTE, NI LabVIEW, or gRPC interfaces supporting C++, Java, and Python
- Develop and execute test scripts using the embedded Spyder Python integrated development environment (IDE)
- Perform comprehensive post-processing analysis within the same environment
PNT signal generation
- Emulate inertial sensor data through the SimINERTIAL feature
- Generate S-band, custom waveforms, and low Earth orbit (LEO) PNT signals as standard
- Apply realistic dynamics to I/Q files in real time using patented I/Q spatial awareness - supporting novel PNT signal generation alongside native GNSS signals
Over-the-air testing
- Test complete PNT solutions including the antenna in anechoic chamber environments
- Configure individual or combined output modes from a single system
- Deploy fixed antenna array setups or advanced zoned chamber solutions with positioners and multipath modeling
Keysight’s PNT X is a revolutionary simulation system that addresses the increasing complexity of the positioning, navigation, and timing (PNT) environment. This all-in-one solution generates all global navigation satellite system (GNSS) constellations, radio frequency (RF) threats, and signals of opportunity available for comprehensive test coverage and high realism. In an era when compromising on PNT performance is not an option, PNT X delivers new patented capabilities, simplified software for configuring complex test scenarios, and critical simulation integrity to ensure trustworthy results.
PNT X is the 6th generation of Keysight’s GNSS and PNT simulators. Its flexible software-defined hardware architecture comprises a signal generator and a dedicated C50 X host controller running Keysight’s SimGEN software
