ITECH IT8812C Electronic DC load 120 V, 60 A, 250W

additional images:

DC Input Ratings:

  • Maximum power 250 W
  • Resolution: 10 mW
  • Voltage: 0-18 V and 0-120 V
  • Resolution: 1 mV/10 mV
  • Current: 0-6 A and 0-60 A
  • Resolution: 0.1 mA/1 mA
  • Resistance: 0.3-10 Ohm/10 Ohm to 7.5 kOhm

Operating modes:

  • Constant Voltage
  • Constant Current
  • Constant Resistance
  • Constant Power

Setup Accuracy:

  • Voltage: (0.025%+0.05% Full Scale)
  • Current: (0.05%+0.05% Full Scale)
  • Resistance: 0.01%+0.08S
  • Power: 0.2%+0.2% Full Scale

Feature set:

  • Intilligent fan control. Low acoustic noise
  • Accurate readback of current and voltage
  • Readback sampling to 50 kHz
  • Dynamic test to 25 kHz
  • LIST mode with programable rise/fall time
  • SCPI programming
  • Remote sense
  • Extensive protection functions
  • High accuracy and resolution

Connectivity:

  • RS-232 and USB
  • Analog control
Price

kr 7.984*
* excluding VAT free shipping (Denmark)

Product Number:

IT8812C

Manufacturer:

ITECH

Quantity:

Total
Unit price
base price
Stock
Call or email for delivery time
  • The IT8800 series of loads covers power ranges from 150~55KW and customized solutions over 55KW.
  • The loads have extensive protection function. OVP/OCP/OPP/OTP.
  • They includes dynamic mode. The highest testing speed of current and voltage is 50KHZ,. Memory for 100 sets of data.
  • The current cumsumption is measured and digitized at a rate up to 50 kHz. For even higher speed a current monitor output is available. The output generates 0-10 Volt signal.
  • The loads supports external analog control as well as built-in RS232 and USB interface to make your control the instrument conveniently. Software is provided to automate test.
  • The programmable high-accuracy electronic load has a special LED mode which supports LED power drive test and programmable interface specifications to simulate LED current.
