ITECH IT-M7723D 750 VA Programmable AC/DC Power Supply (High Crest Factor)
AC Output Ratings:
- Output frequency: 45 Hz to 1000 Hz
- Maximum Output Power: 750 VA/750 W
- Maximum Output voltage: 300 Vrms
- Resolution 0.1 V
- RMS Current: 7.5 A
- Peak Current: 45 A
- CF=6 for inrush current test
Feature set:
- Built-in AC power meter with powerful functions
- AC, DC, AC + DC output modes, DC voltage offset simulation in AC + DC mode
- Dimmer function
- Power line disturbance simulation
- Comprehensive protection functions
Connectivity:
- Optional RS232, CAN, LAN, GPIB, USB_TMC,USB_VCP and analog
Documents and Software Solutions:
ITECH newly-launched IT-M7700 High Performance Programmable AC Power Supply combines intelligence and flexibility, breaks through the huge defects of the traditional AC power source, reduces the size and maximizes space utilization.
The IT-M7723 is 1U high and full-rack width.
Built-in power meter and arbitrary waveform generator make it convenient to simulate various arbitrary waveform outputs.
IT-M7700 is designed with advanced technologies of programmable AC and DC power supplies, and can be widely used in multiple fields such as power energy products, home appliances, industrial electronics, avionics, military and IEC standards testing.
ITECH newly-launched IT-M7700 High Performance Programmable AC Power Supply combines intelligence and flexibility, breaks through the huge defects of the traditional AC power source, reduces the size and maximizes space utilization.
The IT-M7723 is 1U high and full-rack width.
Built-in power meter and arbitrary waveform generator make it convenient to simulate various arbitrary waveform outputs.
IT-M7700 is designed with advanced technologies of programmable AC and DC power supplies, and can be widely used in multiple fields such as power energy products, home appliances, industrial electronics, avionics, military and IEC standards testing.
